NI 美国 PXIE-1095 机箱控制器

NI美国PXIe-1095机箱控制器是一款高性能的PXI Express机箱控制器，具有出色的性能和广泛的应用范围。以下是关于该机箱控制器的详细信息：

主要特点

1. 高性能：PXIe-1095机箱控制器提供了高达24 GB/s的系统带宽，满足了各种高性能测试和测量应用的需求。
2. 插槽配置：该机箱提供了18个插槽，包括12个PXIe插槽、5个混合插槽和1个PXI Express系统定时插槽，为用户提供了极大的灵活性和扩展性。
3. 电源和冷却：每个插槽都配备了高达82 W的电源和冷却功能，确保在高负载下稳定运行。
4. 可热插拔电源：机箱包含两个可热插拔电源，提高了系统的平均修复时间（MTTR），增加了系统的可靠性。
5. 定时和同步：提供了一个可选的定时和同步升级选项，包括一个内置的恒温晶体振荡器（OCXO），用于提高时钟精度以及实现外部时钟和触发路由。

技术规格

• 系统带宽：高达24 GB/s
• 插槽数量：18个（12个PXIe插槽，5个混合插槽，1个PXI Express系统定时插槽）
• 电源和冷却：每个插槽82 W
• 电源类型：两个可热插拔电源
• 板载时钟类型：OCXO（可选）
• 外部时钟和触发：支持

应用领域

PXIe-1095机箱控制器广泛应用于需要高性能、高精度和可靠性的测试和测量应用中，如工业自动化、半导体测试、航空航天等领域。

兼容性

PXIe-1095机箱控制器兼容PXI、PXI Express和PXI混合模块，可以与其他NI和第三方厂商的模块协同工作，为用户提供完整的测试解决方案。

The NI American PXIe-1095 chassis controller is a high-performance PXI Express chassis controller with outstanding performance and a wide range of applications. Here are the details about the chassis controller:

Main feature

High performance: The PXIe-1095 chassis controller provides up to 24 GB/s of system bandwidth to meet the needs of a variety of high-performance test and measurement applications.

Slot configuration: The chassis provides 18 slots, including 12 PXIe slots, 5 hybrid slots, and 1 PXI Express system timing slot, providing users with great flexibility and scalability.

Power and cooling: Each slot is equipped with power and cooling capabilities up to 82 W, ensuring stable operation under high loads.

Hot-swappable Power supplies: The chassis contains two hot-swappable power supplies, which improves the mean time to repair (MTTR) of the system and increases system reliability.

Timing and synchronization: An optional timing and synchronization upgrade option is provided, including a built-in thermostatic crystal oscillator (OCXO) for improved clock accuracy as well as external clock and trigger routing.

Technical specification

System bandwidth: up to 24 GB/s

Number of slots: 18 (12 PXIe slots, 5 hybrid slots, 1 PXI Express system timing slot)

Power and cooling: 82 W per slot

Power Supply type: Two hot swappable power supplies

On-board clock Type: OCXO (optional)

External clock and trigger: Supported

Application field

The PXIe-1095 chassis controller is widely used in test and measurement applications that require high performance, precision and reliability, such as industrial automation, semiconductor testing, aerospace and other fields.

compatibility

The PXIe-1095 chassis controller is compatible with PXI, PXI Express, and PXI hybrid modules and can work with modules from other NI and third-party vendors to provide users with a complete test solution.
